LINED ‘V’ PORT BALL

Valve Diagram

LINED ‘V’ PORT CONTROL BALL VALVE

Valve Diagram
P.T.No Part Name Material
1
Body
DI / WCB / CF8M
2
Body End
3
Ball with integral stem
4
Seat Ring
PTFE
5
Stem Bearing
6
Gland Box
DI / WCB / CF8M
7
Bush
PTFE
8
Gland Packing
PTFE
9
Gland Nut
ASTM A276 TYPE 316
10
Gasket
PTFE
P.T.No Part Name Material
11
Stopper Plate
STEEL
12
Handle Cup
STEEL
13
Stud
ASTM A193 Gr.B7 318
14
Nut
ASTM A194 Gr.2H-316
15
Hex Bolt
STEEL SS316
16
Socket Headscrew
STEEL
18
Hex-Bolt
STEEL
19
Lever Rod
STEEL
20
Linning
FEP/PFA
All dimensions are in mm
F-F
Size
F Dia
F T
R F Dia
R F T
P.C.D
NOH
SOH
W.L
G.L
C-H
Class
Class
Class
Class
Class
Class
Class
150#
300#
150#
300#
150#
300#
150#
300#
150#
300#
150#
300#
150#
300#
15
106
140
89
85
10
14
35
1.5
60
67
4
4
16
16
152
70
73
20
117
152
96
118
10
16
43
1.5
70
83
4
4
16
16
152
73
76
25
127
165
108
124
11
17
51
1.5
79
89
4
4
16
19
178
89
95
40
165
190
127
156
14
21
73
1.5
98
114
4
4
16
22
229
105
111
50
178
216
152
165
16
22
92
1.5
121
127
4
8
19
19
305
114
121
65
203
283
190
210
19
28
105
1.5
140
149
4
8
19
22
457
130
141
80
203
263
190
210
19
28
127
1.5
152
168
4
8
19
22
457
114
121
100
229
305
229
254
24
32
157
1.5
190
200
8
8
18
22
762
152
171
150
267
403
279
318
25
37
216
1.5
241
270
8
12
22
22
224
190
216
200
282
419
343
381
29
42
270
1.5
298
330
8
12
22
25
406
228
254
